23 TECHNICAL DATA
166
Screw, chain sliding guard M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch lever M6 5 Nm (3.7 lbf ft)
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, fuel tank spoiler on radiator M6 6 Nm (4.4 lbf ft)
Screw, manifold on silent block M6 6 Nm (4.4 lbf ft)
Screw, oil pump M6 6 Nm (4.4 lbf ft)
Screw, oil tank on frame M6 5 Nm (3.7 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, seat fixing M6 10 Nm (7.4 lbf ft)
Screw, silent block on frame M6 6 Nm (4.4 lbf ft)
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Fuel connection on fuel pump M8 15 Nm (11.1 lbf ft)
Nut, foot brake lever M8 20 Nm (14.8 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, pull switch (All XC‑W models) M8 0.8 Nm (0.59 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp (All
standard models)
M8 15 Nm (11.1 lbf ft)
Screw, bottom triple clamp (All
special models)
M8 15 Nm (11.1 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine brace M8x15 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, engine brace M8x20 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, engine sprocket cover M8 15 Nm (11.1 lbf ft)
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, manifold M8 15 Nm (11.1 lbf ft)
Screw, side stand attachment (All
EXC models)
M8x20 33 Nm (24.3 lbf ft)
Loctite
®
2701™
Screw, side stand attachment (All
XC‑W models)
M8x26 33 Nm (24.3 lbf ft)
Loctite
®
2701™
Screw, subframe bottom M8 30 Nm (22.1 lbf ft)
Loctite
®
2701™
Screw, subframe top M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top steering stem (All stan-
dard models)
M8 20 Nm (14.8 lbf ft)
To Next Page
