6 CONTROLS
23
6.21 Foot brake lever
401956-10
Foot brake lever
1
is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.22 Side stand
401943-10
Side stand
1
is located on the left side of the vehicle.
401944-10
The side stand is used for parking the motorcycle.
Info
When you are riding, side stand
1
must be folded up and
secured with rubber band
2
.
6.23 Steering lock (All EXC models)
V00328-10
Steering lock
1
is fitted on the left side of the steering head.
The steering lock is used to lock the steering. Steering, and there-
fore riding, is no longer possible.
