ENGLISH
37
MAINTENANCE WORK ON CHASSIS AND ENGINE »
Check/set distance of the magnetic sensor
The distance between the magnet [2] and the sensor [1] must be 2-4 mm,
otherwise malfunctions on the speedometer might occur.
This distance can be corrected by screwing the sensor [1] in or off.
Replacing the headlight lamp/parking light lamp
Loosen both rubber bands and tilt the headlight mask to the front. Pull the
parking light lamp with holder [3] carefully out of the reflector. Pull
connector [4] off the headlamp and remove rubber cap [5]. Disengage retain-
ing clip and take the bulb out of the reflector. When changing the parking-
light lamp, simply pull it out of the holder.
Slightly depress the bulb, turn it approx. 30° counterclockwise and pull it out
of the socket.
To mount the lamp reverse the worksteps indicated above.
1
1
2
3
5
4
