KTM 300 MXC User Manual

ENGLISH
46
CHASSIS 125 SX 125 EXC 200 EXC
Frame Central chrome-moly-steel frame
Fork White Power – Upside down 48 MA
Wheel travel front/rear 300/335 mm (11.8/13.2 in)
Rear suspension WP PDS 5018 (Progressive Damping System) shock absorber, aluminium swingarm
Front brake Disc brake with carbon-steel brake disc Ø 260 mm (10.2 in), brake caliper floated
Rear brake Disc brake with carbon-steel brake disc Ø 220 mm (8.7 in), brake caliper floated
Brake discs Wear limit 2.50 mm (0.1 in) front / 3.50 mm (0.14 in) rear
Front tires 80/100 - 21“51M, M59 90/90 - 21“ MT 83 90/90 - 21“ MT 83
Front tires USA 80/100 - 21“51M, M59 – 80/100 - 21“ 51M, M59
Air pressure offroad 1,0 bar (14 psi) 1,0 bar (14 psi) 1,0 bar (14 psi)
Air pressure road driver only – 1,5 bar (21 psi) 1,5 bar (21 psi)
Rear tires 100/90 - 19“ 57M, M70 120/90 - 18“ MT 83 120/90 - 18“ MT 83
Rear tires USA 100/90 - 19“ 57M, M70 – 100/100 - 18“ 59M, M402
Air pressure offroad 1,0 bar (14 psi) 1,0 bar (14 psi) 1,0 bar (14 psi)
Air pressure road driver only – 2,0 bar (28 psi) 2,0 bar (28 psi)
Fuel tank capacity 7.5 liters (2 US gallons) 8.5 liters (2.2 US gallons) 8.5 / 10.5 liters (2.2 / 2.8 US gallons)
Final drive ratio 13:50 t 14:42 t 14:42 t
Final drive ratio USA 13:50 t 13:50 t 14:48 t
Chain 5/8 x 1/4 "
Available final sprockets 38t, 40t, 42t, 45t, 48t, 49t, 50t, 51t, 52t
Bulbs headlight 12V 35/35W Bilux (base Ba20d)
parking light 12V 5W (base W2, 1x9,5d)
brake-rear light 12V 21/5W (base BaY15d)
flasher light 12V 10W (base Ba15s)
license plate illumination 12V 1,2W (base 1x4,6d)
Steering head angle 63°
Wheel base 1471 ± 10 mm (57.9 in ± 0.4 in)
Seat height, unloaded 925 mm (36,5 in)
Ground clearance, unloaded 390 mm (15,3 in)
TECHNICAL SPECIFICATIONS – CHASSIS 125 SX, EXC, 200 EXC »
STANDARD ADJUSTMENT – FORK
125 SX 125/200 EXC
WP 4860 MA-PA WP 4860 MA
14187A01 14187A02
Compression adjuster 20 22
Rebound adjuster 20 21
Spring 4,2 N/mm 3,8 N/mm
Spring preload 5 mm 5 mm
Air chamber length 100 mm 110 mm
Fork oil SAE 5 SAE 5
STANDARD ADJUSTMENT – SHOCK ABSORBER
125 SX 125/200 EXC
WP PDS 5018 DCC WP PDS 5018 MCC
12187A01 12187A02
Compression adjuster 15 LS (low speed) 15
1,5 HS (high speed)
–
Rebound adjuster 22 22
Spring 72 N/mm linear 72 N/mm linear
Spring preload 7 mm 7 mm

KTM 300 MXC Specifications

General

Starter	Kickstarter
Bore x Stroke	72 mm x 72 mm
Fuel System	Carburetor
Rear Suspension	WP monoshock
Front Brake	Single 260mm disc
Rear Brake	Single 220mm disc
Fuel Tank Capacity	9.5 liters
Frame	Chromium-Molybdenum steel
