TECHNICAL SPECIFICATIONS 4
21
4.1 chassis tightening torques
Screw, air filter box cover EJOT PT
®
K60x20-Z 3 Nm (2.2 lbf ft)
Screw, air filter box, on subframe EJOT PT
®
K60x20AL 5 Nm (3.7 lbf ft)
Screw, combination switch EJOT PT
®
K50x18 T20 2 Nm (1.5 lbf ft)
Screw, fuel pump on fuel tank EJOT PT
®
K60x30-Z 2.5 Nm (1.84 lbf ft)
Screw, intake air temperature sen-
sor
EJOT PT
®
K50x18 T20 0.7 Nm (0.52 lbf ft)
Screw, radiator hoses clip 2.4 Nm (1.77 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, start/stop button EJOT PT
®
K50x18 T20 2 Nm (1.5 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, throttle valve body hose
clamp
M4 5 Nm (3.7 lbf ft)
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, frame protector M5 3 Nm (2.2 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screw, throttle valve body cover M5 2.6 Nm (1.92 lbf ft)
Screws on main silencer M5 7 Nm (5.2 lbf ft)
Nut, starter cable on starter motor M6 4 Nm (3 lbf ft)
Nut, throttle cable on throttle valve
body
M6 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, battery holding bracket M6 6 Nm (4.4 lbf ft)
Screw, brake line guide on link
fork
M6 4.5 Nm (3.32 lbf ft)
Screw, chain guide on link fork at
the front
M6x45 10 Nm (7.4 lbf ft)
Screw, chain guide on link fork at
the rear
M6x16 10 Nm (7.4 lbf ft)
Screw, chain sliding guard on link
fork
M6 6 Nm (4.4 lbf ft)
Screw, connector board with com-
bination instrument
M6 5 Nm (3.7 lbf ft)
Screw, fender to triple clamp M6 12 Nm (8.9 lbf ft)
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, fuel tank spoiler on radiator M6 6 Nm (4.4 lbf ft)
Screw, ground wire on frame M6 10 Nm (7.4 lbf ft)
Screw, hand lever M6 5 Nm (3.7 lbf ft)
Screw, push rod ball joint on the
rear brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
