KTM 690 Enduro R 2018 User Manual

TROUBLESHOOTING 20
227
Faults Possible cause Action
Engine turns but does not start. Throttle opened while starting – When starting, DO NOT open the throt-
tle
– Carry out the start procedure.
( p. 57)
Engine has too little power. Air filter is very dirty – Remove the air filter. ( p. 103)
– Install the air filter. ( p. 104)
Fuel screen is very dirty – Change fuel screen.
Fuel filter is very dirty – Check the fuel pressure.
Defect in fuel injection system – Read out the fault memory using the
KTM diagnostics tool.
Map‑Select switch incorrectly
adjusted
– Adjust the engine characteristic.
( p. 203)
Engine overheats. Too little coolant in cooling sys-
tem
– Check the cooling system for leakage.
– Check the coolant level. ( p. 193)
Radiator fins very dirty – Clean radiator fins.
Foam formation in cooling sys-
tem
– Drain the coolant. ( p. 195)
– Fill/bleed the cooling system.
( p. 197)
Buckled or damaged radiator
hose
– Change the radiator hose.
Thermostat is faulty – Check the thermostat.

KTM 690 Enduro R 2018 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	690 cc
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP USD Ø 48 mm
Rear Suspension	WP shock absorber with Pro-Lever linkage
Rear Brake	Brembo single-piston floating caliper, 240 mm disc
Front Tire	90/90-21
Rear Tire	140/80-18
Seat Height	910 mm
Ground Clearance	270 mm
Fuel Tank Capacity	13.5 liters
Dry Weight	146 kg
Fuel System	Electronic fuel injection (EFI)
Frame	Chromoly steel trellis frame
Front Brake	300 mm disc
ABS	Bosch
Front Wheel	21-inch
Rear Wheel	18-inch
Power	67 hp (49.5 kW) @ 7500 rpm
Wheelbase	1504 mm
