KTM 790 DUKE 2018 User Manual

13 SERVICE WORK ON THE CHASSIS
148
V01265-10
– Check the chain sliding guard for wear.
» If continuous signs of wear to the chain are visible on the
chain sliding guard in the area
D
marked:
– Replace the chain sliding guard.
» If the chain sliding guard is highly worn on the underside
in the marked area
E
:
– Replace the chain sliding guard.
– Check that the chain sliding guard is firmly seated.
» If the chain sliding guard is loose:
– Tighten the screws on the chain sliding guard.
Guideline
Remaining screws,
chassis
M5 5 Nm (3.7 lbf ft)
Finishing work
– Remove the rear of the motorcycle from the lifting gear.
( p. 130)

KTM 790 DUKE 2018 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, parallel twin
Displacement	799 cc
Bore x Stroke	88 mm x 65.7 mm
Compression Ratio	12.7:1
Starter	Electric
Transmission	6-speed
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	825 mm
Dry Weight	169 kg
Power	105 hp (77 kW) @ 9, 000 rpm
Torque	87 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Frame	Steel trellis frame
Front Suspension	WP upside-down Ø 43 mm
Rear Suspension	WP monoshock
Front Brake	2 x 300 mm discs, 4-piston calipers
Rear Brake	240 mm disc, single-piston caliper
ABS	Bosch 9.1MP Two Channel ABS (incl. Cornering ABS and Supermoto mode)
Fuel Tank Capacity	14 liters
