KTM 790 DUKE 2018 User Manual

ELECTRICAL SYSTEM 16
197
Tip
Replace spare fuse
4
in the fuse box so that it is
available if needed.
– Mount the protection cap.
Finishing work
– Mount the passenger seat. ( p. 136)
16.7 Changing the fuses of individual power consumers
Warning
Fire hazard Incorrect fuses overload the electrical system.
– Only use fuses with the required ampere value.
– Do not bypass or repair fuses.
Info
The fuse box containing the fuses of individual power consumers is located under the seat.
Preparatory work
– Switch off the ignition by turning the ignition key to the posi-
tion .
– Remove the passenger seat. ( p. 135)

KTM 790 DUKE 2018 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, parallel twin
Displacement	799 cc
Bore x Stroke	88 mm x 65.7 mm
Compression Ratio	12.7:1
Starter	Electric
Transmission	6-speed
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	825 mm
Dry Weight	169 kg
Power	105 hp (77 kW) @ 9, 000 rpm
Torque	87 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Frame	Steel trellis frame
Front Suspension	WP upside-down Ø 43 mm
Rear Suspension	WP monoshock
Front Brake	2 x 300 mm discs, 4-piston calipers
Rear Brake	240 mm disc, single-piston caliper
ABS	Bosch 9.1MP Two Channel ABS (incl. Cornering ABS and Supermoto mode)
Fuel Tank Capacity	14 liters
