COMBINATION INSTRUMENT 7
57
7.10 Time
H02856-10
The time
1
is displayed in 24 hour format in all languages
except for EN-US. The time
1
is displayed in 12 hour format if
the language is set to EN-US.
The time can be configured in the Clock/Date menu.
Info
The time must be reset after the battery was disconnected
or the fuse was removed.
7.11 Coolant temperature indicator
H02616-01
Note
Engine failureOverheating damages the engine.
If the coolant temperature warning is displayed, stop imme-
diately and take care not to endanger yourself or other traffic
participants in the process.
Allow the engine and cooling system to cool down.
Check and, if necessary, correct the coolant level on the cool-
ing system while it is in a cooled state.
The temperature indicator consists of eight bars. The more bars
that light up, the hotter the coolant.
