KTM 790 DUKE 2018 User Manual

TECHNICAL DATA 23
251
Screw, shift shaft sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, thermostat case M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Remaining screws, engine M6 10 Nm (7.4 lbf ft)
Screw, alternator cover M6x30 10 Nm (7.4 lbf ft)
Screw, alternator cover M6x35 10 Nm (7.4 lbf ft)
Screw, bleeder flange EJOT screw M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, camshaft bearing support M6 10 Nm (7.4 lbf ft)
Screw, chain shaft M6 10 Nm (7.4 lbf ft)
Screw, clutch basket retaining
bracket
M6 10 Nm (7.4 lbf ft)
Screw, clutch cover M6 10 Nm (7.4 lbf ft)
Screw, clutch release lever M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch spring M6 10 Nm (7.4 lbf ft)
Screw, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, engine case M6x30 10 Nm (7.4 lbf ft)
Screw, engine case M6x60 10 Nm (7.4 lbf ft)
Screw, heat exchanger M6 10 Nm (7.4 lbf ft)
Screw, ignition coil M6 8 Nm (5.9 lbf ft)

KTM 790 DUKE 2018 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, parallel twin
Displacement	799 cc
Bore x Stroke	88 mm x 65.7 mm
Compression Ratio	12.7:1
Starter	Electric
Transmission	6-speed
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	825 mm
Dry Weight	169 kg
Power	105 hp (77 kW) @ 9, 000 rpm
Torque	87 Nm @ 8, 000 rpm
Fuel System	Electronic fuel injection
Frame	Steel trellis frame
Front Suspension	WP upside-down Ø 43 mm
Rear Suspension	WP monoshock
Front Brake	2 x 300 mm discs, 4-piston calipers
Rear Brake	240 mm disc, single-piston caliper
ABS	Bosch 9.1MP Two Channel ABS (incl. Cornering ABS and Supermoto mode)
Fuel Tank Capacity	14 liters
