KTM 790 Duke 2019 User Manual

15 WHEELS, TIRES
166
15.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 131)
– Lift the motorcycle with the front lifting gear. ( p. 132)
V01243-10
Main work
–
Remove screw
1
and pull wheel speed sensor
2
out of the
hole.
–
Remove screws
3
.
– Press back the brake linings by slightly tilting the left brake
caliper laterally on the brake disc. Pull the left brake caliper
carefully back from the brake disc and hang to the side.
Info
Do not operate the hand brake lever if the brake caliper
has been removed.
–
Remove screws
4
.
– Press back the brake linings by slightly tilting the right brake
caliper laterally on the brake disc. Pull the right brake caliper
carefully back from the brake disc and hang to the side.
Info
Do not operate the hand brake lever if the brake caliper
has been removed.

KTM 790 Duke 2019 Specifications

General

Displacement	799 cc
Bore x Stroke	88 mm x 65.7 mm
Compression Ratio	12.7:1
Power	105 hp (77 kW) @ 9, 000 rpm
Torque	87 Nm @ 8, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	825 mm
Dry Weight	169 kg
Engine Type	2-cylinder, 4-stroke, parallel twin
Frame	Chromoly-steel trellis frame, powder coated
Front Suspension	WP upside-down fork, 43 mm
Front Brake	2 x 300 mm disc, 4-piston radial fixed caliper
Rear Brake	240 mm disc with single-piston caliper
Fuel Tank Capacity	14 liters
ABS	Bosch 9.1 MP (incl. Cornering-ABS and Supermoto mode)
