KTM 790 Duke 2019 User Manual

17 COOLING SYSTEM
214
V01255-10
Main work
–
Remove radiator cap
1
and cap
2
of the compensating
tank.
– Check the antifreeze in the coolant.
Antifreeze −25 … −45 °C (−13 …
−49 °F)
» If the antifreeze in the coolant does not match the speci-
fied value:
– Correct the antifreeze in the coolant.
– Check the coolant level in the compensating tank.
The coolant level must be between MIN and MAX.
» If the coolant level in the compensating tank is not at the
required level, but the tank is not empty:
– Replenish coolant up to a level between MIN and MAX.
Coolant ( p. 271)
» If there is no coolant in the compensating tank:
– Check the cooling system for leaks.
Info
Do not start up the motorcycle!
– Fill/bleed the cooling system. ( p. 219)
–
Mount cap
2
of the compensating tank.
– Check the coolant level in the radiator.

KTM 790 Duke 2019 Specifications

General

Displacement	799 cc
Bore x Stroke	88 mm x 65.7 mm
Compression Ratio	12.7:1
Power	105 hp (77 kW) @ 9, 000 rpm
Torque	87 Nm @ 8, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Rear Suspension	WP monoshock
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	825 mm
Dry Weight	169 kg
Engine Type	2-cylinder, 4-stroke, parallel twin
Frame	Chromoly-steel trellis frame, powder coated
Front Suspension	WP upside-down fork, 43 mm
Front Brake	2 x 300 mm disc, 4-piston radial fixed caliper
Rear Brake	240 mm disc with single-piston caliper
Fuel Tank Capacity	14 liters
ABS	Bosch 9.1 MP (incl. Cornering-ABS and Supermoto mode)
