22 TECHNICAL DATA
136
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 8 mm (0.31 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 42 N/mm (240 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 45 N/mm (257 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 48 N/mm (274 lb/in)
Spring length 240 mm (9.45 in)
Gas pressure 10 bar (145 psi)
Static sag 35 mm (1.38 in)
Riding sag 105 mm (4.13 in)
Fitted length 456.3 mm (17.965 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 140)
22.9 Chassis tightening torques
Screw, air filter box cover EJOT PT
®
K60x20-Z 3 Nm (2.2 lbf ft)
Screw, air filter box, on subframe EJOT PT
®
K60x20AL 5 Nm (3.7 lbf ft)
Screw, combination switch EJOT PT
®
K50x18 T20 2 Nm (1.5 lbf ft)
Screw, fuel pump on fuel tank EJOT PT
®
K60x25-Z 2.3 Nm (1.7 lbf ft)
Screw, intake air temperature sen-
sor
EJOT PT
®
K50x18 T20 0.7 Nm (0.52 lbf ft)
Screw, radiator hoses clip 2.4 Nm (1.77 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, start/stop button EJOT PT
®
K50x18 T20 2 Nm (1.5 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, throttle valve body hose
clamp
M4 5 Nm (3.7 lbf ft)
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, frame protector M5 3 Nm (2.2 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screw, throttle valve body cover M5 2.6 Nm (1.92 lbf ft)
Screws on main silencer M5 7 Nm (5.2 lbf ft)
Nut, starter cable on starter motor M6 4 Nm (3 lbf ft)
Nut, throttle cable on throttle valve
body
M6 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
