CONTROLS 6
19
6.13 Shift lever
401950-10
Shift lever
1
is mounted on the left side of the engine.
401950-13
(All SX‑F models)
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second
gears.
401950-11
(XC‑F US)
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second
gears.
6.14 Foot brake lever
401956-10
Foot brake lever
1
is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
