13
BRAKE
SYSTEM
116
L02135-11
–
Disconnect
spring
.
–
Release
nut
and
use
screw
to
adjust
the
specified
free
travel
.
Guideline
Free
travel
at
foot
brake
lever
3…
5
mm
(0.12…
0.2
in)
Info
The
range
of
adjustment
is
limited.
–
Hold
screw
and
tighten
nut
.
–
Attach
spring
.
117
119
