14
WHEELS,
TIRES
130
400695-01
–
Remove
the
dust
cap.
–
Check
tire
air
pressure
when
the
tires
are
cold.
Tire
air
pressure,
solo
Front
2.0
bar
(29
psi)
Rear
2.0
bar
(29
psi)
Tire
air
pressure
with
passenger/fu
ll
payload
Front
2.0
bar
(29
psi)
Rear
2.2
bar
(32
psi)
»
If
the
tire
air
pressure
does
not
meet
specifications:
–
Correct
the
tire
air
pressure.
–
Mount
the
dust
cap.
131
133
