17 TUNING THE ENGINE 159
» If the clutch lever play changes:
– Check the routing of the clutch cable.
17.4 Adjusting the clutch cable play
L02155-10
– Move the handlebar to the straight-ahead position.
–
Push back sleeve
.
–
Loosen lock nut
.
–
Adjust the play in the clutch level
by turning adjusting screw
.
Guideline
Clutch lever play 1… 3 mm (0.04… 0.12 in)
–
Tighten lock nut
.
–
Position bellows
.
