17OPERATING THE TRACTOR
2. Fold the ROPS.
To avoid personal injury:
A Hold the ROPS tightly with both hands and fold
the ROPS slowly and carefully.
3. Insert both set bolts and secure them with the hair
pins.
To avoid personal injury:
A Make sure that both set bolts are properly
installed and secured with the hair pins.
BTo Raise the ROPS to Upright Position
1. Remove both hair pins and set bolts.
2. Raise ROPS to the upright position, maintain a hold on
the ROPS.
To avoid personal injury:
A Raise the ROPS slowly and carefully.
3. Insert both set bolts and secure them with the hair
pins.
To avoid personal injury:
A Make sure that both set bolts are properly
installed as soon as the ROPS is in the upright
position and secured with the hair pins.
(1) ROPS
(1) Set bolt
(2) Hair pin
(1) Set bolt
(2) Hair pin
(1) Set bolt
(2) Hair pin
