11SPECIFICATIONS OF THE BACKHOE
Hydraulic cylinders
Bucket Sizes
Boom
cm (in.)
Dipperstick
cm (in.)
Bucket
cm (in.)
Stabilizer
cm (in.)
Swing
cm (in.)
Rod diameter 3.0 (1.18) 2.5 (0.98) 2.5 (0.98) 2.5 (0.98) 3.0 (1.18)
Cylinder bore 6.5 (2.56) 6.0 (2.36) 5.0 (1.97) 6.0 (2.36) 6.0 (2.36)
Width
cm (in.)
SAE truck
Capacity
m (cu-ft)
SAE Heaped
Capacity
m (cu-ft)
Number
of
Teeth
Weight
kg (lbs)
Trenching 8" 20.3 (8) 0.009 (0.317) 0.011 (0.402) 2 10 (22)
Trenching 12" 30.5 (12) 0.014 (0.510) 0.020 (0.690) 3 13 (29)

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
