51TIRES, WHEELS AND BALLAST
BRear Wheels
Rear tread width can not be adjusted.
A Do not turn rear discs to obtain wider tread.
A Always attach tires as shown in the drawings.
A If not attached as illustrated, transmission parts may be damaged.
A When re-fitting or adjusting a wheel, tighten the bolts to the following torques then recheck after driving the tractor 200m
(200yards) and thereafter daily check service.
A Use the tapered bolts for wheels with beveled or tapered holes.
Tire 26x12.00-12 Turf, Bar, and Ind.
Tread
(1) Bolt Front 149.2 to 179.0 N-m
(15.2 to 18.3 kgf-m)
(110 to 132 ft-lbs.)
Rear 108.5 to 130.2 N-m
(11.1 to 13.3 kgf-m)
(80 to 96 ft-lbs.)
