3SPECIFICATIONS OF THE TRACTOR
SPECIFICATIONS OF THE TRACTOR
SPECIFICATION TABLE
Model BX25DLB
PTO power *1 kW (HP) 13.2 (17.7)
Engine
Maker KUBOTA
Model D902
Type Indirect injection, vertical, water-cooled, 4-cycle diesel
Number of cylinders 3
Bore and stroke mm (in.) 72 x 73.6 (2.83 x 2.90)
Total displacement cm (cu. in.) 898 (54.8)
Engine gross power *2 kW (HP) 17.1 (23.0)
Rated revolution rpm 3200
Low idling revolution rpm 1350 to 1550
Maximum torque N-m (lbf-ft) 56.1 (41.4)
Battery 12V, RC: 80min, CCA: 540A
Fuel Diesel fuel No.2 [above -10 (14 )] Diesel fuel No.1 [below -10 (14 )]
Capacities
Fuel tank L (U.S.gals.) 25 (6.6)
Engine crankcase (with filter) L (U.S.qts.) 3.1 (3.3)
Engine coolant L (U.S.qts.) 2.7 (2.8)
Recovery tank L (U.S.qts.) 0.4 (0.4)
Transmission case L (U.S.gals.) 11.6 (3.1)
Dimensions
Overall length (without 3P) mm (in.) 2120 (83.5)
Overall length (with 3P) mm (in.) 2425 (95.5)
Overall width mm (in.) 1145 (45.1)
Overall height
(with ROPS) mm (in.) 2215 (87.2)
mm (in.) 1255 (49.4) (Top of seat)
Wheel base mm (in.) 1400 (55.1)
Min. ground clearance mm (in.) 175 (6.9)
Tread
Front mm (in.) 930 (36.6)
Rear mm (in.) 820 (32.2)
Weight (with ROPS) kg (lbs.) 720 (1587)
Clutch N / A
Traveling
system
Tire
Front 18 x 8.50-10 (Turf, Bar, Ind.)
Rear 26 x 12.00-12 (Turf, Bar, Ind.)
Steering Hydrostatic type power steering
Transmission Main: Hydrostatic transmission, High-Low gear shift (2 forward, 2 reverse)
Brake Wet disk type
Min. turning radius m (feet) 2.3 (7.5)
