Kubota BX2670 User Manual

17OPERATING THE TRACTOR
3. Align set pin holes, insert both set pins. Secure them
with the hair pins.
To avoid personal injury:
A Make sure that both set pins are properly
installed as soon as the ROPS is in the upright
position and secured with the hair pins.
4. Tighten the holding knob bolts.
BAdjustment of Foldable ROPS
A Adjust free fall of the ROPS upper frame regularly.
A If you feel less friction in folding the ROPS, tighten the
nut (1) until you feel the right friction in the movement.
(1) Set pins
(2) Hair pins
(1) Holding knob bolts
(1) Nut

Kubota BX2670 Specifications

General

Transmission	Hydrostatic
Hydraulic System Type	Open center
3-Point Hitch	Category I
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
Power Take-off (PTO)	Independent
Rear PTO RPM	540
Mid PTO RPM	2500
Steering	Power Steering
Brakes	Wet disc
Engine Type	Diesel
PTO Horsepower	19.4 hp (14.5 kW)
Fuel Tank Capacity	6.6 gal (25 L)
Hydraulic Pump Capacity	6.3 GPM (23.8 L/min)
Lift Capacity at 24"	680 lbs (308 kg)
Wheelbase	55.1 in (1400 mm)
Horsepower	25.5 hp (19 kW)
