19OPERATING THE MACHINE
BHydraulic Lift Lever
The hydraulic lift lever is used to raise and lower
implement used with the machine (ex. Mower).
To lower implement, push the lever FORWARD.
To raise it, pull the lever BACKWARD.
A Do not operate until the engine is warmed up. If
operation is attempted when the engine is still cold, the
hydraulic system may be damaged.
A Do not operate at slow Engine rpm. Move the throttle
lever above 1/2.
A If noises are heard when implement is lifting after the
hydraulic lift lever has been activated, the hydraulic
mechanism is not adjusted properly. Contact your
local KUBOTA Dealer for adjustment.
BThrottle Lever
Pulling the throttle lever backward decreases the engine
speed and pushing it forward increases the engine speed.
BParking Brake
To release the parking brake, depress the brake pedal
again.
3. Raise the implement.
(1) Hydraulic lift lever : "DOWN"
N: "NEUTRAL"
: "UP"
4. Accelerate the Engine.
(1) Throttle lever : "FAST"
: "SLOW"
5. Unlock the Parking Brake.
(1) Brake pedal
