TIRE AND WHEELS
32
WHEELS
A
When re-fitting a wheel, tighten the wheel b
olts to the
following torques then recheck after travelling 200 m
(220 yards) changing directions several times.
A
Wheels with beveled or tapered holes:
Use the tapered wheel bolts. (Front)
(1) Bolt
Front 108.5 to 130.2 N-m
(11.07 to 13.28 kgf-m)
(
80 to 96 lb
f-ft)
(1) Nut
(2) Spring wash
er
Rear 77.6 to 90.2 N-m
(
7.9 to 9.2
kgf-m)
(
57.2 to 66
.5 lbf-ft)
48
50
Table of Contents
