3SPECIFICATIONS
ENGLISH
GENERATOR
Model Unit
J110 J112 J114
-STD -SA -STD -AUS -STD -SA
Design
Salient-pole, revolving-field AC generator
(AVR system with separate and self-excitation brush)
Frequency Hz 60 50 60
Rated Output (COP)
kVA 10 12 14
11.5/
14.0
kW 10 12 14
11.5/
14.0
Rated Voltage V 110/220 127/220 220 240 110/220 127/220
Phase & Wire φ-w 1-3 1-2 1-3
Power Factor % 100
No. of Poles - 2
Insulation - Rotary coil: Class F, Stator coil: Class B
Voltage Regulation %
7 (No load to full
load)
8 (No load to full load)
Type of Coupling Direct coupled
DIESEL ENGINE
Model D722-B-SEC D1005-BG-SEC
Design Vertical, water-cooled, 4-cycle diesel engine
No. of cylinders 3
Bore x stroke mm φ67 x 68 φ76 x 73.6
Displacement L 0.719 1.001
Engine speed rpm 3600 3000 3600
Lubricating Oil API service class CD or higher
Oil capacity L 3.4 4.3
Coolant capacity L 3.0 3.3
SET
Fuel Diesel fuel No. 2 (ASTM D975)
Fuel consumption (at full load) L 4.2 4.5 5.8
Fuel tank capacity L 37 79
Continuous Operating Hours hrs 8.5 17.0 13.5
Battery (V x Ah/5Hr)
55B24R
(12V x 36Ah)
80D26R(S)
(12V x 55Ah)
Starting System Electric
L x W x H (with wheel) mm
995 x 593 x 860
(1037)
1215 x 611 x 922
Approx Net Wt. kg 255 340
Output
Terminal - -
Receptacle---- --
Option Caster - -
Sound Level (full load at 7m) dB(A) 76.5 76.5 81.0
Emergency Stop System -
In case of
abnormal: Oil
pressure, water
temperature
In case of abnormal: Oil pressure, water
temperature, fan belt broken
AMPS
AMPS A
90.9/
45.5
78.7/
45.5
54.5 50.0
63.6 x 2
/63.6
90.6/
63.6
