4 SPECIFICATIONS
ENGLISH
GENERATOR
Model Unit
J116 J119
-STD -AUS -STD -SA
Design
Salient-pole, revolving-field AC generator
(AVR system with separate and self-excitation brush)
Frequency Hz 50 60
Rated Output (COP)
kVA 16 18.8 11.5/18.8
kW 16 18.8 11.5/18.8
Rated Voltage V 220 240 110/220 127/220
Phase & Wire φ-w 1-2 1-3
Power Factor % 100
No. of Poles - 2
Insulation - Rotary coil: Class F, Stator coil: Class B
Voltage Regulation % 8 (No load to full load)
Type of Coupling Direct coupled
DIESEL ENGINE
Model V1305-BG-SEC
Design Vertical, water-cooled, 4-cycle diesel engine
No. of cylinders 4
Bore x stroke mm φ76 x 73.6
Displacement L 1.335
Engine speed rpm 3000 3600
Lubricating Oil API service class CD or higher
Oil capacity L 5.7
Coolant capacity L 3.5
SET
Fuel Diesel fuel No. 2 (ASTM D975)
Fuel consumption (at full load) L 6.0 7.5
Fuel tank capacity L 79
Continuous Operating Hours hrs 13.0 10.5
Battery (V x Ah/5Hr) 80D26R(S) (12V x 55Ah)
Starting System Electric
L x W x H (with wheel) mm 1300 x 611 x 922
Approx Net Wt. kg 380
Output
Terminal - -
Receptacle - - - -
Option Caster - -
Sound Level (full load at 7m) dB(A) 77.5 82.0
Emergency Stop System -
In case of abnormal:
Oil pressure, water temperature, fan belt broken
AMPS
AMPS A 72.7 66.7
85.5 x 2
/85.5
90.6/85.5
