Kubota M6060 User Manual

4 SPECIFICATIONS
Hydraulic
unit
Hydraulic control system Position, draft (top link sensing) & mix control
Pump capacity
L (U.S.gals.) /
min
41.6 (11.0) (F8/R8 model)
61.5 (16.2) (F12/R12 model)
3-point hitch Category 1 and 2
Max. lifting
force
At lifting
points *3
kg (lbs.) 1900 (4189)
24 in.
behind
lifting
point
kg (lbs.) 1500 (3307)
Remote hydraulic control 1 standard (2nd, 3rd valve optional)
System pressure
MPa
(kgf/cm )
19.1 (195)
Traction system Swinging drawbar, adjustable in direction
PTO
Live PTO
(Indepen-
dent)
Direction of turning Clockwise, viewed from tractor rear
PTO/
Engine
speed
rpm
6 spline: 540 / 2160 (F8/R8 model)
6 spline: 540 / 2160, 540E/1828 (F12/R12 model)
The company reserves the right to change the specifications without notice.
NOTE: *1 Manufacturer's estimate
*2 Cast iron disks available for wheels.
*3 At lower link end with links horizontal.
Model
M6060 M7060
2WD 4WD 2WD 4WD

Kubota M6060 Specifications

General

Engine Type	Diesel
Cylinders	4
Fuel Type	Diesel
Hydraulic System	Open center
Lift Capacity	3, 307 lbs
Transmission	8F / 8R
Fuel Tank Capacity	17.7 gal
Displacement	148.5 cubic inches
3-Point Hitch	Category I/II
Horsepower	63.4 HP
