Kubota M6060 User Manual

37OPERATING THE TRACTOR
BCoolant Temperature Gauge
To avoid personal injury or death:
A Do not remove radiator cap until coolant
temperature is well below its boiling point.
Then loosen cap slightly to the stop to relieve
any pressure before removing cap completely.
1. With the key switch at "ON", this gauge indicates the
temperature of the coolant. "C" for "cold" and "H" for
"hot."
2. If the indicator reaches the red zone position, engine
coolant is overheated. Check the tractor by referring to
"TROUBLESHOOTING" section.
BTachometer
The tachometer indicates the engine speed on the dial.
(1) Coolant temperature gauge (A) "RED ZONE"
(1) Engine revolution

Kubota M6060 Specifications

General

Engine Type	Diesel
Cylinders	4
Fuel Type	Diesel
Hydraulic System	Open center
Lift Capacity	3, 307 lbs
Transmission	8F / 8R
Fuel Tank Capacity	17.7 gal
Displacement	148.5 cubic inches
3-Point Hitch	Category I/II
Horsepower	63.4 HP
