Kubota M6060 User Manual

7IMPLEMENT LIMITATIONS
A Implement size may vary depending on soil operating conditions.
*1 Must remove front weight with this implement.
*2 Need subframe
No. Implement Remarks
M6060 M7060
2WD 4WD 2WD 4WD
1Slurry Tank
Max. Tank Capacity L (gals.) 3000 (790)
Max. Load Capacity kg (lbs.) 4000 (8800)
2Trailer
Max. Load Capacity kg (lbs.) 4500(9900) 5000 (11000) 4500(9900) 5000 (11000)
Max. Drawbar Load kg (lbs.) 1000 (2200)
3Mower
Rotary-Cutter
Max. Cutting Width mm (in.) 2130 (84)
Max. Weight kg (lbs.) 540 (1200)
Flail Mower
(Heavy)
Max. Cutting Width mm (in.) 3050 (120)
Max. Weight kg (lbs.) 800 (1760)
Sickle Bar Max. Cutting Width mm (in.) 2130 (84)
4 Sprayer
Max.Tank
Capacity
Mid L (gals.) 680 (180)
Rear 3P L (gals.) 680 (180)
Drawbar L (gals.) 3000(800) 3500 (920) 4000(1030)
5 Rotary Tiller
Max. Tilling Width mm (in.) 2130 (84) 2330 (91)
Max. Weight kg (lbs.) 800 (1760)
6 Bottom Plow
Max. Size
16 in. x 2
18 in. x1
14 in. x 3
16 in. x 2
18 in. x 1
14 in. x 3
16 in. x 2
16 in. x 3
18 in. x 2
Max. Weight kg (lbs.) 3P Type 450 (1000) 550 (1200)
7 Disk harrow
3P Type
Max. Size 18 in. x 24 20 in. x 24
Max. Harrowing Width mm (in.) 2130 (84) 2450 (96)
Max. Weight kg (lbs.) 450 (1000) 550 (1200)
Drawbar Type Max. Harrowing Width mm (in.) 2450 (96) 2750 (108) 3050 (120)
8 Disc Plow
Max. Size
24 in. x 3
26 in. x 2
26 in. x 3
Max. Weight kg (lbs.) 450 (1000) 550 (1200)
9 Sub Soiler
Numbers of Cultivating Tines 2
Cultivating Depth mm (in.) 300 (12) 400 (16) 450 (18)
10 Cultivator
Max. Width mm (in.) 3050 (120) 3660 (144) 4270 (168)
Number of Rows 4
Max. Weight kg (lbs.) 450 (1000) 550 (1200)
11 Front Blade *1, *2
Max. Cutting Width mm (in.) 1820 (72) 2130 (84)
Max. Oil Pressure MPa (psi.) 19.6 (2842)
12 Rear Blade
Max. Cutting Width mm (in.) 1820 (72) 2130 (84)
Max. Oil Pressure MPa (psi.) 19.6 (2842)
13 Front Loader *1, *2
Max. Lifting Capacity
(Bucket Pivot Pin, Max.
Height)
kg (lbs.) 1150 (2535)
Max. Oil Pressure MPa (psi.) 19.6 (2842)
14 Box Blade
Max. Cutting Width mm (in.) 1820 (72) 2130 (84)
Max. Weight kg (lbs.) 450 (1000) 550 (1200)
15 Back Hoe *2
Max. Digging Depth mm (in.) 2530 (100)
Max. Weight kg (lbs.) 900 (2000)
16 Snow Blade
Max. Width mm (in.) 1820 (72) 2130 (84)
Max. Weight kg (lbs.) 450 (1000) 550 (1200)

Kubota M6060 Specifications

General

Engine Type	Diesel
Cylinders	4
Fuel Type	Diesel
Hydraulic System	Open center
Lift Capacity	3, 307 lbs
Transmission	8F / 8R
Fuel Tank Capacity	17.7 gal
Displacement	148.5 cubic inches
3-Point Hitch	Category I/II
Horsepower	63.4 HP
