UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Diesel Fuel
Engine-Rotational Speed
Hourmeter/Elapsed
Operating Hours
Engine
Coolant-Temperature
Diesel Preheat/Glow
Plugs(Low Temperature
Start Aid)
Parking Brake
Engine Intake/Combustion
Air-Filter
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
Electrical
Power-accessories
Engine-Run
Engine-Start
Engine-Stop
Power Take-Off Clutch
Control-Off (Disengaged)
Position
Power Take-Off Clutch
Control-On (Engaged) Position
Bi-Speed turn
Differential Lock
Position Control-Raised
Position
Position Control-Lowered
Position
Engine Warning
Emission Control
Draft Control-Shallow
Position
Draft Control-Deep Position
3-Point Lowering Speed
Control
Remote Cylinder-Retract
Remote Cylinder-Extend
Hazard Warning Lights
Headlight-Low Beam
Headlight-High Beam
4-Wheel Drive-On
4-Wheel Drive-Off
Front-Wheel Drive-On
Fast
Slow
Creep
Windshield Wiper
Windshield Wiper
Intermittent
Windshield Washer
Lock
Rear Window Defroster
Steering Wheel-Tilt Control
Empty
Full
PTO 540 rpm
PTO 1000 rpm
Regeneration
DPF INHIBIT (Switch)
Regeneration (Switch)
Parked Regeneration
Engine RPM Increase
Rev-limiter Control
Constant RPM Management
