Kubota M6060 User Manual

31OPERATING THE TRACTOR
By combination of using the main gear shift lever, the
range gear shift lever and hydraulic-shuttle shift lever,
forward speeds and reverse speeds shown in the table
below are obtained.
6. Selecting the Travel Speed.
(1) Hydraulic - shuttle shift lever
(2) Main gear shift lever
(3) Range gear shift lever
(F) "FORWARD
(N) "NEUTRAL POSITION"
(R) "REVERSE"
(P) "PARK POSITION"
"LOW"
"HIGH"
"CREEP" (if equipped)
F8 / R8 model
Without
creep
8 forward speeds
8 reverse speeds
With
creep
12 forward speeds
12 reverse speeds
F12 / R12 model
Without
creep
12 forward speeds
12 reverse speeds
With
creep
18 forward speeds
18 reverse speeds

Kubota M6060 Specifications

General

Engine Type	Diesel
Cylinders	4
Fuel Type	Diesel
Hydraulic System	Open center
Lift Capacity	3, 307 lbs
Transmission	8F / 8R
Fuel Tank Capacity	17.7 gal
Displacement	148.5 cubic inches
3-Point Hitch	Category I/II
Horsepower	63.4 HP
