Kubota u25 User Manual

Safety alert Symbol
Alarm lamp “Fuel level too low”
Alarm lamp “Engine Oil pressure “
Alarm lamp “Battery charge”
Horn
Diesel
Hydraulic fluid
Fast
Slow
Excavator - Overhead movement toward the front
Excavator - Overhead movement toward the rear
Boom raise
Boom lower
Arm out
Arm in
Bucket in
Bucket dig / rollback
Boom swing (left)
Boom swing (Right)
Dozer raise
Dozer lower
Operation direction of control lever
Operation direction of control lever
Read operator’s manual
Lock
Unlock
GENERAL SYMBOLS
The instruments and operation elements have been marked with a series of symbols in order to simplify the opera-
tion of your excavator. These symbols are listed below with the respective descriptions.

Kubota u25 Specifications

General

Engine Power	14.9 kW (20 hp)
Max Dig Depth	2, 620 mm
Max Reach	4, 740 mm
Max Reach at Ground Level	4, 690 mm
Transport Length	3, 990 mm
Transport Width	1, 490 mm
Transport Height	2, 490 mm
