2-S2
ZD18(F) · ZD21(F) · ZD28(F), WSM
TRANSAXLE
TRAVELLING GEAR SHIFT SECTION
W1014322
PTO SECTION
W1011614
PARKING BRAKE SECTION
W1011333
Symptom Probable Cause Solution
Reference
Page
Noise from
Transmission
• Transmission oil insufficient
• Gear worn or broken
• Bearings worn
Refill
Replace
Replace
–
–
2-S24
PTO Clutch Slip • Operating pressure is low
• PTO clutch valve malfunctioning
• Clutch disc or drive plate excessively worn
Check
Repair or replace
Replace
–
2-S18
2-S19
PTO Shaft Does Not
Rotate
• PTO clutch malfunctioning Repair or replace 2-S18
PTO Clutch
Operating Pressure
Is Low
• Transmission oil improper or insufficient
• Regulator valve malfunctioning
Replenish or change
Check or replace
2-S11
2-S20
PTO Clutch Drags • Brake plate excessively worn
• Clutch spring weaken or broken
• Deformation of pressure plate or steel plate
Replace
Replace
Replace
2-S19
2-S19
2-S19
Brake Drags • Brake spring play too small
• Brake return spring weaken or broken
Adjust
Replace
G-28
–
Poor Braking Force • Brake spring play excessive
• Brake shoe worn
• Grease or oil on brake shoe
Adjust
Replace
Replace
G-28
2-S21
2-S21
KiSC issued 04, 2009 A
