Kubota WSM User Manual

5-S2
ZD18(F) · ZD21(F) · ZD28(F), WSM
ELECTRICAL SYSTEM
CHARGING SYSTEM
W1011953
GAUGES
W1013515
Symptom Probable Cause Solution
Reference
Page
Charging Lamp Does
Not Light When Main
Switch Is Turned ON
• Fuse blown (15 A)
• Wiring harness disconnected or improperly
connected (between main switch AC terminal
and panel board, between panel board and
dynamo)
• Dynamo defective
• Regulator defective
Replace
Repair or replace
Repair or replace
Replace
G-36
–
5-S15
–
Charging Lamp Does
Not Go Off When
Engine Is Running
• Wiring harness disconnected or improperly
connected (between main switch 30 terminal
and dynamo, between panel board and
dynamo)
• Dynamo defective
• Regulator defective
Repair or replace
Repair or replace
Replace
–
5-S15
–
Fuel Gauge Does Not
Function
• Fuel gauge defective
• Fuel level sensor defective
• Wiring harness disconnected or improperly
connected (between fuel gauge and fuel level
sensor)
Replace
Replace
Repair or replace
2-S12
2-S12
–
Coolant Temperature
Gauge Does Not
Function
• Coolant temperature gauge defective
• Coolant temperature sensor defective
• Wiring harness disconnected or improperly
connected (between coolant temperature
gauge and coolant temperature sensor)
Replace
Replace
Repair or replace
5-S18
5-S18
–
