13. BRAKE SYSTEM
13-6
Mongoose/KXR 250
Remove the brake lever bolt and the brake
lever.
Remove the piston rubber cover and snap
ring from the brake master cylinder.
Remove the washer, main piston and spring
from the brake master cylinder.
Clean the inside of the master cylinder and
brake reservoir with brake fluid.
INSPECTION
Check the cylinder inside wall, and spring
for scratch, corrosion or other abnormal
condition.
If any abnormal condition is found, replace
the inner parts or master cylinder.
Rubber Cove
r
Main Piston
Snap Ring
Spring
Master Cylinde
r
Snap Ring Pliers (Close)
Snap Ring
