1. GENERAL INFORMATION
1-16
Mongoose/KXR 250
CABLE & HARNESS ROUTING
Headlight Wire
Pilot Lamp Wire
Handlebar Switch Wire
Ignition Switch Wire
Rear Brake Fluid Hose
Harness Wire
Motor Fan Cor
d
Thermostatic Switch Wire
Left Front Brake Fluid Hose
Right Front Brake Fluid Hose
Thermostatic Sensor Wire
Front Brake Fluid Hose
Stop Switch Cor
d
Throttle Cable
