3. INSPECTION/ADJUSTMENT
3-3
Mongoose/KXR 250
FUEL LINE
Check the fuel tubes and replace any parts,
which show signs of deterioration, damage
or leakage.
THROTTLE OPERATION
Check the throttle to swing for smooth
movement.
Measure the throttle to swing free play.
Free Play (A): 1～4mm
To adjust throttle free play:
Slide the rubber sleeve back to expose the
throttle cable adjuster.
Loosen the lock nut, then turn the adjuster
to obtain the correct free play. (1~4 mm or
0.04~0.16 in)
Tighten the lock nut and reinstall the sleeve.
AIR CLEANER
AIR CLEANER REPLACEMENT
Remove the seat. (See page 2-3)
Unlatch the four retainer clips and remove
the air cleaner housing cover.
Do not smoke or allow flames or sparks
in your working area.
＊
Fuel Filte
