MAINTENANCE
Engine oil inspection
● Start engine and keep idling for a few minutes.
● Stop the engine and stand the scooter on level
ground by center stand.
● Wait a while, remove the oil level dipstick.
● Wipe oil off, then reinsert the oil level dipstick
without screwing in.
● Remove the oil level dipstick. The oil level should
be between the high and low lines on the dipstick.
● If required, add the specified oil so the oil level
reaches the high level line on the dipstick.
Do not overfill.
● Reinstall the oil level dipstick. Check for oil leaks.
WARNING
The engine and related parts can become
very hot. Be careful when inspecting the
oil level so not to suffer burns. Make the
engine and exhaust system cool down
before inspection.
Tightening torque
Engine oil drain bolt: 25N·m (2.5kg·m, 18ft·lb)
Engine oil replacement
Engine oil quality is the major factor that affects
engine life. Change your scooter's engine oil
as specified in the maintenance schedule.
● Warm engine up thoroughly then stop.
● Stand vehicle by using the center stand
● Place an oil container beneath the drain hole.
● Remove the oil level dipstick.
● Remove the drain bolt and drain off thoroughly
● Tighten the drain bolt to the specified torque.
● Add oil to reach the high line on the dipstick
● Screw the oil level dipstick into place securely.
CAUTION
Use the genuine engine oil or another with
the same quality and grade to avoid burnout
on the engine parts.
