56
Dimensions
Overall length...............................2200 mm
Overall width..................................810 mm
Overall height...............1320 /1120/1185mm
Wheel base..................................1500 mm
Capacities
Engine oil (Exchange).........................1.0 L
Transmission oil (Exchange)..............0.12 L
Fuel tank..........................................10.5 L
Curb weight......................................179kg
Engine
Type...............4-stroke, liquid-cooled SOHC
Displacement....................................125cc
Bore and stroke......................54 X 54.5 mm
Compression ratio.............................11.7:1
Max Horsepower.................9.5KW/9000rpm
Max Torque.......................11.0Nm/6500rpm
Spark plug.................................CPR7EA-9
Idle speed.............................175 rpm0±100
Fuel system...........................Fuel injection
Ignition system.............ECU (full transistor)
Starting system ......... Electric starter motor
Chassis
Tire size, front.............................120/70-13
Tire size, rear..............................150/70-13
Brake (front)........................................CBS
Brake (rear).........................................CBS
Electrical
Ignition type................Inductive ignition coil
Battery.........................................12V10Ah
Headlight.............................12V 16W /32W
Tail light...................................13.5V/3.5W
Brake light..............................13.5V/10.8W
Turn signal light..................Front: 12V 2.6W
Rear: 12V 2.16W
Main & H/L Beam fuse...........................15A
ECU & Ignition & Fan fuse......................10A
Charge fuse.........................................30A
SPECIFICATIONS X-Town CT125
