Kyocera ECOSYS M5521cdn User Manual

8-28
Setup and Registration (System Menu) > System Menu
Function Defaults
[System Menu/Counter] key > [▲] [▼] key > [Common Settings] > [OK] key > [▲] [▼] key > [Function Defaults] >
[OK] key
Item Description
Color
Selection
Copy Set the default copying color mode setting.
Value: Full Color, Black & White
Send/Store Select the default color mode for scanning documents.
Value: Full Color, Grayscale, Black & White
Scan Resolution Select the default scanning resolution.
Value: 200×100dpi Norm., 200×200dpi Fine, 200×400dpi S.Fin, 300×300dpi,
400×400dpi U.Fin, 600×600dpi
FAX Resolution
FAX Operation Guide
Orig.Image(Copy) Set the default original document type for copying.
Value: Text+Photo, Photo, Text, Graphic/Map, Printed Document
Orig.Image(Send) Set the default original document type for sending.
Value: Text+Photo, Photo, Text, for OCR, Light Text/Line
NOTE
[for OCR] is only available when "Color Selection" is set to [Black & White].
Zoom Select the enlarged/reduced default when paper size/sending size changed after the originals set.
Value: 100%, Auto
Collate Set the defaults for Collate.
Value: Off, On
Original Orientation Set the original orientation defaults.
Value: Top Edge on Top, Top Edge on Left
Backgrnd(Copy) Set the default Backgrnd Density (Copy).
Value: Off, Manual (Darker 5)
Backgrnd(Send) Set the default Backgrnd Density (Send).
Value: Off, Manual (Darker 5)
EcoPrint Select the EcoPrint default.
Value: Off, On
Skip Blank(Copy) Set the default Skip Blank(Copy) settings.
Value: Off, On
Skip Blank(Send) Set the default Skip Blank(Send) settings.
Value: Off, On
File Name Entry Set an automatically entered name (default) for jobs. Additional information such as Date and
Job No. can also be set.
Value
File Name: Up to 32 characters can be entered.
Additional Info: None, Date, Job No., Job No. + Date, Date + Job No.
Subject/Body Set the subject and body automatically entered (default subject and body) when sending the
scanned originals by E-mail.
Value
Subject: Up to 60 characters can be entered.
Body: Up to 500 characters can be entered.

Kyocera ECOSYS M5521cdn Specifications

General

Paper input type	Cassette, Paper tray
Multi-Purpose tray	Yes
Total input capacity	250 sheets
Total output capacity	- sheets
Maximum input capacity	550 sheets
Total number of input trays	1
Maximum number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	11 s
Time to first page (color, normal)	12.5 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10 s
Time to first copy (color, normal)	12 s
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Scan speed (black)	30 ppm
Scan speed (color)	23 ppm
Optical scanning resolution	600 x 600 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound pressure level (printing)	46.2 dB
Display	LCD
Product color	Black, White
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	41 W
Power consumption (sleep)	1 W
Power consumption (printing)	345 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	ENERGY STAR
Certification	TÜV/GS, CE, ISO 9001, ISO 14001

Weight and Dimensions

Depth	429 mm
Width	417 mm
Height	495 mm
