Kyocera ECOSYS MA3500cifx User Manual

Operation on the Machine > Scanning Document stored in a Custom Box
252
Scanning Document stored in a Custom Box
Follow the steps as below for scanning a document stored in a custom box using the TWAIN driver. When
transmitting using wireless LAN, select the interface dedicated to the send function in advance.
NOTE
• When transmitting using wireless LAN, select the interface dedicated to the send function in advance.
➡ Primary Network (Client) (page 495)
• Before sending a document, confirm that TWAIN driver is installed on a computer and the settings are
configured.
➡ Setting TWAIN Driver (page 106)
• To load a document saved in the Custom Box, select the model name with (Box) from “Model” on the TWAIN
driver configuration screen.
1
Display the screen.
1 Activate the TWAIN compatible application software.
2 Select the machine using the application and display the dialog box.
NOTE
For selecting the machine, see the Operation Guide or Help for each application software.
2
Display lists of documents.
1 Select a custom box stored a document.
If a password has been set for the box, the password entry screen appears. Enter the password and click
the [OK] button. When you select a box, the document files in the Custom Box appear in "Document List".
2 Set how to display the document data. Click the [Setting] button to select each item.
NOTE
For the settings, refer to Help in the dialog box.
3 Click the [OK] button.
3
Scan the originals.
1 Select the document data to be scanned from "Document List".
Enter the document data name in the "Search (Name)" to find the data having the same document data
name or the document data name with the same beginning.
Click the [Detail] button to display the selected document data. When the document data includes
multiple pages, select the checkbox beside the pages you want to scan. The selected pages will be
scanned.

Kyocera ECOSYS MA3500cifx Specifications

General

N-up printing	2, 4
Duplex printing	Yes
Print technology	Laser
Borderless printing	No
Duplex printing mode	Auto
Time to first page (black, normal)	5.7 s
Time to first page (color, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17.5 ppm
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Fax, Print, Scan
Country of origin	Vietnam
Maximum duty cycle	100000 pages per month
Recommended duty cycle	1000 - 3500 pages per month
Replacement cartridges	TK-5370
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PCL XL, PCLm, PDF, PostScript 3, XPS
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.1 s
Time to first copy (color, normal)	7.2 s
Copy speed (black, normal quality, A4)	35 cpm
Memory slots	1
Processor cores	2
Processor family	ARM Cortex-A9
Maximum internal memory	3000 MB
Sound pressure level (standby)	30 dB
Sound pressure level (printing)	51 dB
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cabling technology	10/100/1000Base-T(X)
Security algorithms	SNMPv3, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Package depth	728 mm
Package width	623 mm
Package height	789 mm
Package weight	51000 g
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	0.5 W
Power consumption (copying)	479.1 W
Power consumption (standby)	18.8 W
Power consumption (printing)	449.1 W
Energy Star Typical Electricity Consumption (TEC)	0.34 kWh/week
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Paper tray media types	Labels, Letterhead, Plain paper, Pre-Printed
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-Purpose Tray media weight	60 - 220 g/m²
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Scan speed (black)	60 ppm
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	120 ppm
Duplex scan speed (color)	100 ppm
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	2.5 sec/page
Mac operating systems supported	Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Operating altitude	0 - 3500 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, CE, ENERGY STAR, EPEAT Gold, REACH, RoHS, TUV, WEEE
Cables included	AC
Included cartridge capacity (CMY)	2500 pages
Included cartridge capacity (black)	3500 pages

Weight and Dimensions

Depth	577.5 mm
Width	480 mm
Height	575 mm
