Kyocera ECOSYS P6235cdn User Manual

2-16
Installing and Setting up the Machine > Network Setup
Network Setup
Configuring the Wired Network
The machine is equipped with network interface, which is compatible with network protocols such as TCP/IP (IPv4),
TCP/IP (IPv6), NetBEUI, and IPSec. It enables network printing on the Windows, Macintosh, UNIX and other platforms.
Set up TCP/IP (IPv4) to connect to the Windows network.
Be sure to connect the network cable before configuring the settings.
Connecting LAN Cable (page 2-7)
For other network settings, refer to the following:
Network (page 8-12)
IPv4 setting
1
Display the screen.
[ Menu ] key > [▲] [  ] key >[ Network ] > [ OK ] key > [▲] [  ] key > [ Wired Netwk. Set ] > [ OK ] key
> [▲] [
 ] key >[ TCP/IP Settings ] > [ OK ] key > [▲] [  ] key > [ IPv4 Setting ] > [ OK ] key
2
Configure the settings.
When setting the static IP address
1 [▲] [] key > [DH
CP] > [OK] key > [▲] [] key > [Off] > [OK] key
2 [▲] [] key > [IP Addr
ess] > [OK] key
3 Se
t the IP address.
4 Se
lect the [OK] key.
5 [▲] [] key > [Subn
et Mask] > [OK] key
NOTE
If user login administration is enabled, you can only change the settings by logging in with administrator privileges.
If
user login administration is disabled, the user authentication screen appears. Enter a login user name and
password, and select [Login].
The factory default login user name and lo
gin password are set as shown below.
ECOSYS P6235cdn ECOSYS P7240cdn
Login User Name: 3500 4000
Login Password: 3500 4000
NOTE
You can set any value between 000 and 255.
Use the numeric keys or select the [▲] or [▼] key to enter a number.
Select the [◄] or [►] ke
y to move the position being entered, which is shown highlighted.

Kyocera ECOSYS P6235cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Time to first page (color, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Replacement cartridges	TK-5280K, TK-5280M, TK-5280Y, TK-5280C
Number of print cartridges	-
Page description languages	PCL 5c, PCL 6, PCL XL, PostScript 3, XPS
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2100 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Legal, Letter, Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	RJ-45, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Processor cores	2
Processor family	ARM Cortex
Maximum internal memory	3000 MB
Internal storage capacity	128 GB
Sound power level (standby)	30 dB
Sound pressure level (printing)	52 dB
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	74 W
Power consumption (standby)	0.6 W
Power consumption (printing)	523 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	532 mm
Width	390 mm
Height	469.5 mm
