Operator Panel
1-2
1.1 Operator Panel
The operator panel on top of the printer consists of four indicators and two
keys. The four indicators light, flash, and go off in combination, indicating
the printer’s status. The keys perform operations, such as canceling data,
switching the printer mode between online and offline status, and printing
status pages.
The numbers used in the above figure are referred to in the “Reference”
column of the table on the following page.
1
2
3
4
5
6
To Next Page
