Kyocera FS-4300DN User Manual

A-9
Appendix
General Description of Options
SD/SDHC Memory Card
The printer is equipped with a slot for an SDHC memory card with a maximum size of 32 GB, and an SD memory card with
a maximum size of 2 GB. An SD/SDHC memory card is useful for storing fonts, macros, and overlays.
This enables high-speed printing of multiple copies using an electric sort function. Also, you can use the Job Box functions.
For details, refer to Job Box on page 5-24.
Reading the SD/SDHC Memory Card
Once inserted in the printer’s slot, the contents of the SD/SDHC memory card can be read from the operation panel or
automatically when you power on or reset the printer.
Installing and Formatting the SD/SDHC Memory Card
To use an unused SD/SDHC memory card, you must first use the printer to format the SD/SDHC memory card.
1 Switch off the printer, remove the power cord and then remove the
main controller unit. To read how to remove the main controller unit,
refer to the section on inserting the memory module.
2 Insert the SD/SDHC memory card into the SD/SDHC memory card
slot.
3 Attach the main controller unit to the printer in the reverse procedure
to when it was removed.
4 Format the SD/SDHC memory card from the operation panel. For the
procedure for formatting, refer to Format SD Card (Formatting the
SD/SDHC memory card) on page 4-83.
PF-320 Paper Feeder
The optional paper feeder PF-320 will each hold approximately 500
sheets of paper. Up to 4 optional feeders can be added to the bottom of
the printer, allowing continuous feeding of up to 2,500 sheets of paper
when combined with the printer's own cassette.
IMPORTANT When you use the paper feeder, place the papers print-
side down.
The papers that can be used in the cassettes supplied with the paper
feeders are as follows:
Paper size : Envelope Monarch, Envelope #10, Envelope #9, Envelope
#6, Envelope DL, Envelope C5, A5, B5, B6, ISO B5, A4,
Executive, Letter, Legal, OufukuHagaki, Oficio II,
Statement, Folio, Youkei 2, Youkei 4, 216 × 340 mm, 16K
and Other (92 × 162 mm to 216 × 356 mm)
SD/SDHC
Memory
Card Slot

Kyocera FS-4300DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Mobile printing technologies	Not supported
Printing colors	Black
Maximum duty cycle	275000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD, SDHC
Maximum internal memory	1280 MB
Sound power level (standby)	27.4 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	13.1 W
Power consumption (printing)	757 W
Power consumption (PowerSave)	1.6 W
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
