Kyocera FS-C5400DN User Manual

Using the Operation Panel 4-107
Color Regist. Normal (Color registration [Standard])
When using the printer for the first time after set-up or after having moved
it, or if printout of any color (magenta, cyan or yellow) is skewed, use this
mode to correct the color registration on the operation panel.
The options available in Registration Normal (Color registration
[standard]) are as follows:
• Print Chart (Printing the color registration correction chart)
• Adjust Magenta (Magenta correction)
• Adjust Cyan (Cyan correction)
• Adjust Yellow (Yellow correction)
Print Chart (Printing the color registration correction chart)
You can use this option to print a color registration correction chart for use
in correcting the color registration.
1 In the Adjust/Maint. menu screen, press U or V to select Color
Regist..
2 Press [OK]. The Color Regist. menu screen appears.
Press [Exit] ([Right Select]) to return to the standby screen.
3 Press U or V to select Normal.
4 Press [OK]. The Color Regist. Normal menu screen appears.
Press [Exit] ([Right Select]) to return to the standby screen.
5 Press U or V to select Print Chart.
6 Press [OK]. A confirmation screen appears.
If Job Accounting is enabled, enter the account ID in the login screen
that appears. A confirmation screen appears after login.
Press [Yes] ([Left Select]). A confirmation screen appears.
Pressing [No] ([Right Select]) returns you to the Color Regist.
Normal menu screen without printing the registration chart.
The printed chart is the color registration correction chart shown on the
next page.
The printed color registration correction chart includes left (L), vertical (V)
and right (R) registration charts for each color (cyan, magenta and
yellow).
Color Regist.: a b
1 Normal
2 Detail
[ Exit ]
Normal: a b
1 Print Chart
2 Adjust Magenta
3 Adjust Cyan
[ Exit ]
Print.
Are you sure?
z Registration chart
[ Yes ] [ No ]

Kyocera FS-C5400DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Maximum internal memory	1280 MB
Sound power level (standby)	36, 36.1 dB
Sound pressure level (printing)	52.1, 55 dB
Total output capacity	500 sheets
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Network ready	No
Mobile printing technologies	-
Compatible operating systems	Mac OS X 10.2, UNIX, LINUX
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	91 W
Power consumption (printing)	608 W
Power consumption (PowerSave)	10 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Gray
Maximum duty cycle	150000 pages per month
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	510 mm
