Kyocera FS-C5400DN User Manual

2-10 Printing Operation
Status Monitor
The Status Monitor monitors the printer status and provides an ongoing
reporting function. It also allows you to specify and modify settings for
printers not included in the KX driver.
The Status Monitor is installed automatically during KX driver installation.
Accessing the Status Monitor
Use either of the methods listed below to launch the Status Monitor.
• Launch when printing starts:
When you specify a printer and start a print job, one Status Monitor is
launched for each printer name. If Status Monitor startup is requested
from multiple printers, Status Monitors are launched for each printer
that issues the request.
• Launch from the KX driver properties:
Click the Status Monitor button in the Advanced tab. Then click
Open Status Monitor button in the Status Monitor dialog box to
launch the Status Monitor.
Exiting the Status Monitor
Use either of the methods listed below to exit the Status Monitor.
• Exit manually:
Right-click the Status Monitor icon in the taskbar and select Exit in the
menu to exit the Status Monitor.
• Exit automatically:
The Status Monitor automatically shuts down after 5 minutes if it is not
being used.
Screen Overview
The screen overview of the Status Monitor is as follows.
Pop-up window
If an information notification event occurs, a pop-up window appears. This
window only appears when the 3D View is open on the desktop.
Pop-up window
3D View
Status Monitor icon

Kyocera FS-C5400DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Maximum internal memory	1280 MB
Sound power level (standby)	36, 36.1 dB
Sound pressure level (printing)	52.1, 55 dB
Total output capacity	500 sheets
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Network ready	No
Mobile printing technologies	-
Compatible operating systems	Mac OS X 10.2, UNIX, LINUX
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	91 W
Power consumption (printing)	608 W
Power consumption (PowerSave)	10 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Gray
Maximum duty cycle	150000 pages per month
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	510 mm
