A-13
Paper Types
†
Cassette
(Optional
Paper
Feeder
PF-500)
Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color, Prepunched, High
quality, and CUSTOM 1 (to 8)
Cassette
(Optional Paper Feeder
PF-510)
Plain, Preprinted, Labels, Bond, Recycled, Rough, Letterhead, Color,
Prepunched, Envelope, Cardstock, Coated, Thick, High quality, and CUSTOM 1
(to 8)
MP Tray Plain, Transparency, Preprinted, Labels, Bond, Recycled, Vellum, Rough,
Letterhead, Color, Prepunched, Envelope, Cardstock, Coated, Thick, High
quality, and CUSTOM 1 (to 8)
Paper Feed
Source
Capacity
Cassette 500 sheets (80 g/m
2
)
MP Tray 150 sheets (80 g/m
2
)
Margin 4 mm (left, right, top and bottom)
Output Tray
Capacity
Top Tray 500 sheets (80 g/m
2
)
Operation
Environment
Temperature 10 to 32.5 °C (50 to 90.5 °F)
Relative Humidity 15 to 80 %
Altitude 2,000 m (6562 feet) maximum
Illumination 1,500 lux maximum
Power Source 120 V, 60 Hz, max. 9.7 A (U.S.A./Canada) 220-240 V, 50 Hz/60 Hz, max. 4.9 A
(European countries) Max. allowable voltage fluctuation: ±10 % Max. allowable
frequency fluctuation: ±2 %
Power
Consumption
Maximum 1,157W or less (U.S.A./canada) 1,146W or less (European countries)
During Printing 628W (U.S.A./canada) 608W (European countries)
During Standby 80W (U.S.A./canada) 91W (European countries)
During Sleep Mode 10 W
Power Off 0 W
Operating
Noise
††
During Printing LpA = 55 dB (A)
During Standby LpA = 36 dB (A)
During Sleep Mode immeasurably low
Dimensions (W × D × H) 345 × 518 × 512 mm
13-5/8 × 18-1/2 × 20-3/16"
Weight Approx. 37 kg (82 lbs)
†. When using CUSTOM 1 (to 8), use the MP tray for paper sizes smaller than 105 × 148 mm (4-1/8 × 5-13/16
inches). The MP tray can be used with paper sizes over 70 × 138 mm (2-3/4 × 5-7/16 inches).
††. Sound pressure level at bystander position [front] in accordance with EN ISO 7779.
