LAI Games Stacker User Manual

Operator's Manual – Stacker Wall Street
© LAI GAMES
Page 34
FB66 PINOUTS
Components Side
Solder side
GND 1
A GND
GND 2
B GND
+12VDC 3
C +12V
+12VDC 4
D +12V
Prize Door Open sensor 4 P1A7 5
E P1B7 Test Button input
Prize Door Open sensor 3 P1A6 6
F P1B6 Service Button input
Prize Door Open sensor 2 P1A5 7
H P1B5 Start Button input
Prize Door Open sensor 1 P1A4 8
J P1B4
Prize Door Lock sensor 4 P1A3 9
K P1B3
Prize Door Lock sensor 3 P1A2 10
L P1B2 Coin 1 input
Prize Door Lock sensor 2 P1A1 11
M P1B1 Coin 2 input
Prize Door Lock sensor 1 P1A0 12
N P1B0 Select Button input
(watch dog) P1C7 13
P P2C7 Display 7 Seg data
P1C6 14
R P2C6 Prize Light 4 (Red)
Prize Light 3 (Red) P1C5 15
S P2C5 Prize Light 4 (Green)
Prize Light 3 (Green) P1C4 16
T P2C4 Display,RSL clock
Prize Light 1 (Green) P1C0 17
U P2C0 RSL data 1
Prize Light 1 (Red) P1C1 18
V P2C1 RSL data 2
Prize Light 2 (Green) P1C2 19
W P2C2
Prize Light 2 (Red) P1C3 20
X P2C3
GND 21
Y GND
GND 22
Z GND
JST 7
JST 5
P2A0 1
1 P2B0 Ticket Drive
P2A1 2
2 P2B1 Start Button Light
P2A2 3
3 P2B2 Coin 1 Counter
P2A3 4
4 P2B3 Coin 2 Counter
P2A4 5
5 P2B4
P2A5 6
6 P2B5 Select Button Light
Prize Lock Motor drive 1 P2A6 7
7 P2B6 Prize Lock Motor drive 3
Prize Lock Motor drive 2 P2A7 8
8 P2B7 Prize Lock Motor drive 4
