Maintenance
5.1.4
Enter the Password for the
Access Level
In the main P
ASSWORD ENTRY menu,
select
Enter passw
ord via
and
ENTER
.
Access level 1:
Factory setting:
Customer Level
0000 – access to custo
mer fu
nctions only
Customers
can
change
the
password
for
access
level
1. Fo
r
detai
ls
ask
the burner manufacturer
/supplier
Access level 2:
Service level
Password: c
ustomer
specific
Access to customer an
d service functions
