Introduction
WiBox2100E User Guide 12
Ad Hoc Network
Figure 2-2. Ad Hoc Network Example
In the example above, the AP is not present. The PC makes a direct wireless
connection with the WiBox to manage serial devices. Without an AP, it is a peer-to-
peer relationship.
Serial Tunneling – Infrastructure
Figure 2-3. Serial Tunneling Infrastructure Example
In the example above, the WiBox communicates with another device server via the
AP. The UDS device server, in this example, is connected via an Ethernet connection
to the AP. In this way, the WiBox and the device server communicate directly and
can transfer information between their serial devices.
